Engine

Cummins 8.9L ISLe (6ISLe450 31) 450 hp, 335 kW, 6-cylinder turbo-diesel, Euro 3

Cooling System

Custom Solution

• Radiator with intercooler and A/C radiator

• Viscous fan clutch driven by the crankshaft

• Transmission, differential, and transfer case cooling integrated into the power unit

Transmission

Allison 3200SP 6-speed automatic

Transfer Case

ZF VG750 permanent all-wheel drive

• 2-speed

• Transfer case lock

• Towing capability

• High-range ratio 1:1

• Low-range ratio 2:1

Differential and Hub Type

Axeltech 4000 series with air intake system

Suspension

Hydropneumatic independent suspension

• Wheel travel – 300 mm

• Light and compact A-type control arms

• Robust construction

• Upper and lower control arms, 4 hydropneumatic nitrogen-charged struts with integrated shock absorbers

Brakes / ABS

Knorr-Bremse

• Pneumatic system equipped with ABS

• Rear parking brake

Wheels

• Tires: Michelin 16.00 R20 XZL

• All-terrain tread

• Rim: Split rims

• Total: 4 units

Rear Ramp

Hydraulic rear ramp with adjustable opening/closing speed

Central Tire Inflation System (CTIS)

Pre-programmed rapid selection on the dashboard with variable payload and terrain settings:

• Terrain Setting 1: Highway

• Terrain Setting 2: Cross-country

• Terrain Setting 3: Mud, Sand, Snow

• Terrain Setting 4: Emergency

• Payload Setting 1: Curb Weight

• Payload Setting 2: Half Load

• Payload Setting 3: Gross Weight

Fuel Capacity

250L tank, diesel fuel

Steering

Hydraulic power steering

Travel Speed

• Highway — 100 km/h

• Off-road — 60 km/h

Acceleration

• 0-60 km/h < 20 sec

• 0-100 km/h < 35 sec

Braking Distance

• 60-0 km/h — 25 m

• 100-0 km/h — 40 m

Operational Range

700 km in mixed mode

Turning Circle

< 16 m

Service Brakes

30° Gradient

Parking Brakes

20° Gradient

Ambient Temperature Range

From -20°C to + 55°C (without preparation)

Altitude Operation

Capable of operations at altitudes over 5000 m

Electrical System

24 V

Alternator

260 A

Main Batteries

24 V

Auxiliary Batteries

24 V

Internal Outlets

24 V, 12 V, 5 V

• Multiple cigarette lighter and USB ports in driver and crew cabins

External Power Socket

24 V NATO power sockets at the front and rear of the vehicle

Front Lights

• 2 x High beam headlamps

• 2 x Low beam headlamps

• 2 x Daytime running lights

• 2 x Side lights

• 2 x Fog lights

• 2 x BLACKOUT lights

Rear Lights

• 2 x Reversing lights

• 2 x Rear stop lights

• 1 x Additional stop light (top)

• 2 x Side lights

• 1 x Additional light (rear)

• 2x BLACKOUT rear stop lights

• 2x BLACKOUT side lights

Interior Lighting

• 2x LED white (Driver and co-driver)

• 6x LED white (Crew)

Crew Compartment Ballistic Protection

PZSA-6

Engine Compartment Ballistic Protection

PZSA-6

Mine Protection (Engine and Crew Compartments)

STANAG-4569 level 3a+4b with potential to upgrade to 4a+4b

IED (Explosive Devices)

50 kg TNT, side blast

Crew Seats

Mine-resistant with 4-point seat belts

Fire Suppression System

• Crew Cabin: Charged with fluoroketone

• Engine Compartment: Powder

• Wheels: Powder

Configuration

Left-hand/Right-hand drive

Seating

• Adjustable driver and co-driver seats

• 8 rear seats facing inward/outward

Entry/Exit

• 1 x hydraulic rear door with exit hatch + blast locks

• 2 x Crew hatches

• 2 x Side doors (Driver and Co-driver)

Air Conditioning

12 kW Cooling/Heating capacity

Driver Video Surveillance System

1 X Rear view camera with protection (roof-mounted, effective in low light). Images displayed on the driver's instrument panel

Turret

User-defined option

Other

• Power-adjustable heated side mirrors

• Variable speed wipers

• Interior floor mats and trim

• Insulation and noise suppression

NATO Standard Towing Device

External Water Containers

20L Capacity x 2

Spare Parts Kit

EW (Electronic Warfare) Kit

360° Surveillance Kit with Night Vision

8-ton Winch

Heated Glass System

Anti-icing elements on windshield and side windows of the driver's cabin

High Beam

Infrared headlamps

8-ton Winch

Mounted on the rear bumper, can be removed and installed on the front bumper

Additional Fluid Storage

2 x 20L Jerry cans

Surveillance System

Alert System

Vehicle Camera
