Armored Vehicle

MAC TI

A multi-purpose armored vehicle with B7 protection class. It offers protection, speed, and power in a single solution. This type of vehicle is suitable for complex tasks requiring both maneuverability and reliability. Battle-tested and recommended as a primary transport vehicle in combat conditions.

MAC TI
MAC TI
Additional data
(4)

  • Turret CEN level B7 & 4569 STANAG II

  • Armored glass CEN level B7 & 4569 STANAG II

  • Number of doors: 4x side / 1x rear, single-leaf

  • Spare tire CEN level B7 & 4569 STANAG II

Engine and Transmission
(8)

  • Engine Type

    4.5L V8 – Diesel / 1VD-FTV (EGR)

  • Cylinder Count

    8 (eight), V-type

  • Wheel Arrangement

    4x4

  • Power

    195 hp at 3300 rpm

  • Torque

    430 Nm (43.8 kg-m) at 1200-3200 rpm

  • Fuel Tank Capacity

    180 (90+90) liters (dual tanks)

  • Transmission Type

    5-speed manual

  • Gear Count

    5 forward and 1 reverse

Overall Dimensions and Vehicle Weight
(8)

  • Length

    5280 mm

  • Height

    With turret 2854 mm; without turret 2295 mm

  • Width

    1890 mm

  • Wheelbase

    3180 mm

  • Gross Weight (Excluding cargo and crew)

    4820 kg (with turret)

  • Ground Clearance

    225 mm

  • Approach Angle

    32°

  • Departure Angle

    24°

Technical Specifications
(9)

  • Total Seating

    8 persons, including driver

  • Seating Configuration

    2x – in cabin / 2x – folding seats behind cabin / 4x – in crew compartment

  • Seat Belts

    Reinforced, 4-point

  • Gun Ports

    6x sides / 2x rear

  • Emergency Hatch

    6x sides / 2x rear

  • Gun Turret

    1 combined mechanical turret with 360° rotation

  • Air Conditioning Systems

    1x factory cabin / 1x additional crew compartment

  • Door Count

    4x side / 1x rear, single-leaf

  • Fire Extinguisher

    Dry powder 4.5 kg
